Low voltage Insulation piercing connectors PCT13 manufacturer from China CROP Technology Co.ltd

Low voltage Insulation piercing connectors

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: PCT13

Production Capacity: 200000pcs/day

Delivery Date: as demand

Material: Plastic

Main cable: 6-150mm2

Means of Transport: Ocean

Packing: 100pcs/carton

Type: Wire Rope Clip

Brand Name: CROP

Branch cable: 6-150mm2

INSULATION PIERCING CONNECTORS IPC'S FOR COVERED CONDUCTOR TO BARE CONNECTION + COVERED TO COVERED CONDUCTOR CONNECTION

Insulation Piercing/Displacement Connectors for Aerial Bundled Cable system

CROP PCT13 150/150
Isolated main conductor: 6-150sqmm
Isolated tap conductor: 6-150sqmm

-600 V
-Copper/Aluminum Wire
-Wire Size 6-150sqmm Solid/Stranded (Run), 6-150sqmm Solid/Stranded (Tap)
-Splice, Tap Connection
-Temperature Rating 90 Deg C
-Standard Package
-Approval Ul 486-B, GB13140.4-1998,GB/T2317.3-2000 and DL/T765.3-2004, NFC 33020
-Easy Tap
